Description
Technical Parameters
Core Mechanical Properties & Dimensional Benchmarks
| Model No. | Wire Diameter (mm) | Toe Load Range (kgf) | Buckling Pressure (kN) | Hardness (HRC) | Fatigue Life (Cycles) | Opening Width (mm) | Core Material | Compliance Standard |
|---|---|---|---|---|---|---|---|---|
| E1609 | 16 | 500-700 | 10-13 | 44-46 | ≥5,000,000 | 28-30 | 60Si2MnA | DIN 17221, GB/T 1222 |
| E1809 | 18 | 750-900 | 10-15 | 44-47 | ≥5,000,000 | 30-32 | 60Si2CrA | BS 970, DIN 17221 |
| E1817 | 18 | 800-950 | 12-16 | 45-48 | ≥6,000,000 | 32-34 | 60Si2MnA | UIC 864, GB/T 1222 |
| E2007 | 20 | 900-1100 | 13-17 | 45-48 | ≥6,000,000 | 31-33 | 55Si2Mn | BS 970, AREMA |
| E2009 | 20 | 1100-1400 | 13-18 | 46-48 | ≥7,000,000 | 33-35 | 60Si2CrA | DIN 17221, UIC 864 |
Matching Components & System Compatibility
| Model No. | Adaptable Rail Type (kg/m) | Matched Rail Shoulder Material | Compatible Rail Pad Material | Rail Insulator Type | Fastener System Compatibility | Installation Requirement | Core Compatibility Advantage |
|---|---|---|---|---|---|---|---|
| E1609 | 43-50 | QT 450-10 | HDPE | Reinforced Nylon 66 | Ordinary Trunk Line Standard System | Manual/Pneumatic Tools | Cost-effective for general lines |
| E1809 | 50-60 | QT 500-7 | Rubber | Reinforced Nylon 66 | Mixed Passenger-Freight Line System | Pneumatic Tools | Balanced for multi-condition use |
| E1817 | 60-UIC 60 | QT 500-7 | EVA | Reinforced Nylon 66 | Heavy-Haul Freight Line System | Hydraulic Tools | High load-bearing with matched components |
| E2007 | 50-60 | QT 450-10 | Rubber | Reinforced Nylon 66 | Urban Rail Transit System | Quick-install Tools | Vibration-absorbing via compatible pad |
| E2009 | 60-UIC 60 | QT 500-7 | EVA | Reinforced Nylon 66 | High-Speed Railway Elastic System | Precision Tools | Stable with high-stiffness shoulder |
