Description
Technical Parameters
Nabla Spring Clips: Technical Data Sheet
| PROPERTY | SPECIFICATION |
|---|---|
| Product Designation | Nabla Δ-Clip (Inverted Delta Profile) |
| Material Composition | 60Si2CrA Spring Steel / U71Mn Railway Steel |
| Heat Treatment | Quenched & Tempered |
| Surface Protection | Electro-galvanized (12-15μm) / Dacromet Coating |
| Mechanical Properties | Hardness: 42-47 HRC • Tensile Strength: 1400-1600 MPa |
| Fatigue Resistance | >5×10⁶ load cycles (UIC 864-5) |
| Operating Temperature | -40°C to +80°C |
| Corrosion Resistance | Salt Spray: 1000 hours (White rust) |
Application & Performance Profile
| CHARACTERISTIC | DETAILS |
|---|---|
| Track Applications | LGV High-Speed Lines • Heavy Axle Load (>25t) • Metro Systems |
| Fastening System | Nabla Complete Fastening Assembly |
| Installation Torque | 180-220 N·m (Hydraulic tool) |
| Design Service Life | 35+ years (Under standard conditions) |
| Key Innovation | Triangular geometry for uniform stress distribution |
| Performance Features | - Vibration damping - Constant toe load maintenance - Crack propagation resistance |
| Quality Certification | TÜV Certified • UIC Approved • EN 13674-1 Compliant |
