SKL15 Railway Track Clip
The SKL15 Rail Clip, part of the Vossloh SKL tension clamp series, is well known for its W-shaped structure, often called a W rail clip. The rail clip, also referred to as an elastic rail clip, track clip, railway clip, or railroad sleeper clip, generates clamping force through bending and twisting. This effectively secures the rails, preventing them from shifting laterally or longitudinally and ensuring that the track gauge remains intact for safe rail vehicle operations. GNEE Rail manufactures a broad range of high-quality rail clips, including W-shaped, E-type, SKL, PR series, NABLA spring clips, Fast clips, and Fist clips, suitable for metro, high-speed, and intercity transport systems. These clips are used extensively across Europe, the U.S., Canada, and other regions. We also provide customized solutions for railway accessories with fast and responsive customer service. Please contact us for more details.
SKL15 Railway Track Clip material composition
| Item Name | Elastic Rail Clip | |||
| Type | E clip (e1809, e2006,e2007,e2009,etc) | |||
| Skl clip (skl1,skl3,skl12,skl14) | ||||
| Or the type by customers' drawings | ||||
| Material | 60Si2MnA | 60Si2CrA | 55Si2Mn | 38Si7 |
| Chemical composition(%) | C:0.56-0.64, Mn:0.60-0.90, Si:1.60-2.00, Cr:≤0.35, P:≤0.03, S:≤0.03 | C:0.56-0.64, Mn:0.40-0.70, Si:1.40-1.80,Cr:0.70-1.00 P:≤0.03, S:≤0.03 | C:0.52-0.60, Mn:0.60-0.90, Si:1.50-2.00,Cr:≤0.35 P:≤0.03, S:≤0.03 | C:0.35-0.42, Mn:0.50-0.80, Si:1.50-1.80, P:≤0.03, S:≤0.03 |
| Hardness | For e clip: 44-48HRC For skl clip: 42-47HRC |
|||
| Fatigue life | for Dia.18 is 3 millions cycles without breaking for Dia.20 is 5 millions cycles without breaking |
|||
| Surface | plain (oiled), Oxide black, color painting, HDG, Zinc Plating... | |||
| Standard refers | DIN17221, BS970, GB/T1222 | |||
SKL15 Railway Track Clips technical parameters
| Item No | Material | Diameter | Clip length | Clip width | Weight | HRC | Pressure | Fatigue Test | Countries |
| SKL1 | 60Si2Mn | ø13 | 133±2.3 | 0.48 | 44-48 | ≥9.5KN | 5000000 times without break | America,brazil | |
| SKL3 | 60Si2Mn | ø13 | 120±2 | 0.48 | 44-48 | ≥9.5KN | 5000000 times without break | America,brazil | |
| SKL12 | 60Si2Mn | ø13 | 0.53 | 44-48 | ≥9.5KN | 5000000 times without break | America,brazil | ||
| SKL14 | 60Si2Mn | ø13 | 155±2 | 0.53 | 44-48 | ≥9.5KN | 5000000 times without break | America,brazil |
SKL15 Railway Track Clips workshop
customer visit for Rail Clip
Participating in the Indonesia exhibition
