Description
Technical Parameters
Assembly Clearance Control & Compatibility Optimization
| Model No. | Clip-Rail Shoulder Clearance (mm) | Clearance Tolerance (±mm) | Compatibility with Rail Fastener Slots | Guide Plate Fit Clearance (mm) | Sleeper Insert Matching Tolerance (mm) | Clearance Impact on Vibration Reduction (%) | Core Compatibility Advantage |
|---|---|---|---|---|---|---|---|
| SKL1-AC | 1.5-2.0 | 0.3 | UIC 54 Standard Slots | 0.8-1.2 | ±0.5 | ≥15 | Universal fit for conventional fasteners |
| SKL3-AC | 1.2-1.8 | 0.25 | Urban Rail Custom Slots | 0.6-1.0 | ±0.4 | ≥20 | Vibration-optimized clearance for subway |
| SKL12-AC | 1.0-1.5 | 0.2 | High-Speed Rail Precision Slots | 0.4-0.8 | ±0.3 | ≥25 | Minimal clearance for high-speed stability |
| SKL14-AC | 1.3-1.9 | 0.28 | Heavy-Haul Freight Reinforced Slots | 0.7-1.1 | ±0.45 | ≥18 | Impact-resistant fit for 35t axle loads |
| SKL21-AC | 0.8-1.3 | 0.15 | Ballastless Track Integrated Slots | 0.3-0.6 | ±0.25 | ≥30 | Ultra-precise fit for slab track systems |
Material Sustainability & Extreme Impact Response
| Model No. | Recycled Material Ratio (%) | Recyclability Grade | Carbon Footprint (kg CO₂/kg) | Extreme Impact Load Resistance (kN) | Impact Deformation Recovery Rate (%) | Biodegradable Coating Ratio (%) | Core Sustainability & Impact Advantage |
|---|---|---|---|---|---|---|---|
| SKL1-SI | ≥85 | R2 (Reusable) | 2.3-2.7 | ≥120 | ≥85 | 30 | Cost-effective sustainability for low-traffic lines |
| SKL3-SI | ≥90 | R1 (Highly Recyclable) | 2.0-2.4 | ≥130 | ≥88 | 45 | Balanced eco-performance for urban rail |
| SKL12-SI | ≥95 | R0 (Near-Full Recyclable) | 1.7-2.1 | ≥150 | ≥92 | 60 | Low-carbon + high impact resistance for high-speed rail |
| SKL14-SI | ≥92 | R1 (Highly Recyclable) | 1.9-2.3 | ≥140 | ≥90 | 50 | Recyclable + impact-resistant for heavy-haul |
| SKL21-SI | ≥98 | R0 (Near-Full Recyclable) | 1.5-1.9 | ≥160 | ≥95 | 75 | Premium sustainability + extreme impact tolerance for ballastless track |
