100-8 Railway Joint Bar
The 100-8 railway fishplate or 100-8 rail joint bar GNEE rail manufactured is a type of rail connector used in railway systems.
GNEE is a trustworthy railway product manufacturer, specializing in high quality railway fasteners. Our railway product selection includes different styles of fish plates tailored for light rail, heavy rail, and crane rails. We are dedicated to offering personalized options to fulfill the distinct needs of our clients. Therefore, we can produce all types of rail fish plates you need. Feel free to contact us for more information.
Rail Joint Types
Rail joints for light rail: 8kg, 9kg, 12kg, 15kg, 18kg, 22kg, 24kg and 30kg
Rail joints for heavy rail: 38kg, 43kg, 50kg and 60kg
Rail joints for crane rail: QU70, QU80, QU100 and QU120
Drawing
Mechanical Property
| No./S | Heat Treatment No. | Quality (pairs) | Chemical Composition | Mechanical Property | |||||||
| C % | Mn % | P % | S % | Tensile Strength Min 690MPa | Yield Point Min 483MPa | Elongation Min 12% | Reduction of Area Min 25% | Bent cold through 90 Deg | |||
| 1 | 2190713 | 200 | 0.52 | 0.62 | 0.023 | 0.034 | 825 | 575 | 16 | 35 | qualified |
Railway Fish Plates Supplier
