50kg 60kg 70kg Mine Heavy Rail Hot Rolling

50kg 60kg 70kg Mine Heavy Rail Hot Rolling

Heavy rail is an important standard in railway construction. Heavy rail is usually used to withstand larger train weights and high-frequency transportation needs.
Send Inquiry
Chat Now
Description
Technical Parameters







Products Description





The heavy rail standard system has become the first choice for high-speed railways, heavy-duty freight lines and key railway trunk lines due to its excellent load-bearing performance, long-term durability and operational stability. This type of rail uses special high-strength steel, combined with precision manufacturing technology and material optimization design, to accurately adapt to the dual needs of modern railway transportation for safety and efficiency.



Technological iteration is continuously promoting breakthroughs in rail performance. The strength, wear resistance and intelligent monitoring level of this type of rail material are showing a significant upward trend. Its heavy-duty structural design enables a single rail to have a stronger load capacity, especially for heavy-duty freight and high-speed passenger systems. Taking the 60kg/m specification as an example, this type of rail can perfectly adapt to the operating requirements of conventional freight trains and high-speed EMUs, showing excellent scene adaptability.





Heavy Steel Rail



Size Rail Height Bottom Width Head Width Web Thickness Weightkg/m
50kg 152 132 70 15.5 51.514
60kg 176 150 73 16.5 60.8
75kg 192 150 75 20 74.64



50kg 60kg 70kg Mine Heavy Rail Hot Rolling50kg 60kg 70kg Mine Heavy Rail Hot Rolling50kg 60kg 70kg Mine Heavy Rail Hot Rolling









Gnee Steel (tianjin) Co., Ltd





Since its establishment in 2008, the company's business has covered more than 160 countries around the world, with customers in Asia Pacific, Europe, Africa, America and other continents. We always uphold professionalism, provide standardized rail products and customized solutions to customers in different regions, and ensure the dual guarantee of product quality and service experience through technology empowerment.



Contact now



50kg 60kg 70kg Mine Heavy Rail Hot Rolling







FAQ





1. Do you provide spare parts and accessories?
Yes, we provide rail accessories such as turnouts, joints, rail fasteners, etc. to help customers better complete the construction and maintenance of railway track systems.



2. Are your rails suitable for heavy-duty railway systems?
Our heavy-duty rails are designed for heavy-duty railway systems. They have high strength and durability and can withstand high-intensity transportation pressure.



3. Do your rails support automated equipment transportation?
Yes, our rail products can be used in modern automated equipment transportation systems, such as self-driving trains and unmanned handling systems.



4. How to choose the rails suitable for your project?
According to the scale, load requirements, environmental conditions, etc. of the project, our technical team can provide professional selection suggestions to help you choose the most suitable rails.
