EN Standard 46E2 Railway Track
The EN Standard 46E2 railway track, also known as "European standard rail," adheres to the European Norm (EN) standards for railway infrastructure, specifically EN 13674-1. This standard outlines the technical specifications for steel rails used in railways. The 46E2 rail is characterized by its specific profile dimensions and weight, making it suitable for medium to heavy traffic applications. With extensive experience in the research, development, production, and sales of railway equipment, we have built a solid foundation of manufacturing expertise. Over the years, our production capabilities have steadily increased, transforming us into a comprehensive company that covers product development, manufacturing, maintenance, and processing of railway equipment. Our primary products include elastic rail fasteners, iron sleeper plates, railway accessories, railway materials, and steel rails. We source high-quality materials from reputable suppliers, such as Q235B, 35# steel, 45# steel, 40Cr, 35CrmoA, and Q345B. Every product undergoes rigorous quality inspections. Please don't hesitate to contact us if you have any needs!
EN Standard 46E2 Railway Track Dimension
| Size | Rail height(mm)
A |
Bottom Width(mm)
B |
Head Width(mm)
C |
Web Thickness(mm)
t |
Weight(kg/m) |
| 39E1(BS80A) | 133.40 | 117.50 | 63.50 | 13.10 | 39.77 |
| 45E1(BS90A) | 142.88 | 127.00 | 66.67 | 13.89 | 45.11 |
| 45E3(RN45) | 142.00 | 130.00 | 66.00 | 15.00 | 44.79 |
| 46E2(U33) | 145.00 | 134.00 | 62.00 | 15.00 | 46.27 |
EN Standard 46E2 Railway Track drawing
