Key Features:
- Quick Installation:
The modular design simplifies the installation process, allowing the fasteners to be quickly secured to the rail sleepers.
- Secure and Reliable:
High clamping force and pull-out resistance ensure a secure hold on the rails, preventing displacement and deformation.
- High Durability:
Made of high-strength materials, they offer excellent wear and fatigue resistance, enabling them to withstand long-term, high-load operation.
- Easy Maintenance:
The modular design makes replacement and maintenance quick and easy, reducing downtime and maintenance costs.
- Adaptability:
Adjustable to suit different line conditions and train types, offering excellent versatility and adaptability.
Comparison of Fast Clip Types
| Type | Clamp Force | Install Time | Best For | Lifespan |
|---|---|---|---|---|
| SKL15 | 15 kN | 30 sec | High-speed/heavy haul | 20+ years |
| Fastclip | 12-14 kN | 20 sec | Mixed passenger/freight | 15-20 years |
| Nabla Clip | 8-10 kN | 10 sec | Urban transit/tram | 12-18 years |
| e-Clip | 10-12 kN | 15 sec | Light rail | 10-15 years |
Quality Control Tests
Static Load Test: 3× design load (e.g., 45kN for SKL15) – no deformation.
Dynamic Fatigue: 5M cycles @ 8-20kN (simulates 10+ years of service).
Corrosion Test: 1000hr salt spray (ISO 9227) – ≤5% white rust.
Electrical Isolation: ≥5kΩ (insulated systems per EN 50122-1).
