Nabla Clips
| Feature | Description |
|---|---|
| Primary Function | To clamp the rail foot to the sleeper, maintaining track gauge and restraining rail movement. |
| Key Principle | Elastic fastening. It acts as a spring, applying a consistent clamping force that absorbs vibrations and allows for thermal expansion. |
| Common Names | Nabla Clip, Wire Clip, Spring Wire Clip. The term "SKL Clip" is often used synonymously, as SKL is a specific, popular brand of Nabla clip. |
| System Components | 1. The Nabla Clip itself (a hardened steel wire). 2. A Tension Washer or Anchor Plate (a critical component for guiding the clip). |
| Advantages | Simple design, excellent elasticity, easy installation and removal (with tools), good resistance to vibration loosening, cost-effective. |
| Disadvantages | Generally provides a lower clamping force than heavier E-clips; may not be suitable for the most extreme heavy-haul applications. |
Comparison with Other Common Fasteners
| Fastener Type | Principle | Comparison with Nabla Clip |
|---|---|---|
| Dog Spike | Rigid fastening for wooden sleepers. | Nabla Clip is superior: Elastic, provides consistent clamping force, suitable for concrete sleepers. |
| E-Clip (e.g., Pandrol) | Elastic fastening; a robust, stamped spring steel clip. | E-Clip typically has a higher toe load and is more massive. Nabla Clip is generally easier and faster to install/remove, especially with automated machinery. |
| Fast Clip (FastenClip) | Elastic fastening; a single-piece rod installed vertically. | Similar performance. Fast Clips are often a two-part system (clip + polymer shoulder), while Nabla clips are a three-part system (clip + metal washer + shoulder). |
