Steel Rail Screw Spikes

The screw spike is also known as rail screw. As one kind of Rail spike, it is a metal screw for fixing rail fasteners. Screw spike is usually made of NO.3 steel. Because its nail rod surface has thread, so it is called screw spike. The pull-out resistance is 0.5 ~ 1.0 times larger than that of common rail spike, but the thrust resistance is 50% less. Due to disassembly and assembly inconvenience, it is difficult to adjust the rail gauge, which is generally used on the railway turnout.For meeting various needs of clients, we can offer coach screws, stud screw, railway sleeper screws and other coustom screw spike in railway.

Send Inquiry

Chat Now

Description

Technical Parameters

Scenario-Adapted Technical Specs

Model	Overall Length	Shank Diameter	Thread Spec (UNC/Metric)	Head Type	Material	Surface Treatment	Drilling Diameter	Pull-Out Force (Min.)	Applicable Sleeper Type	Compliance Stds
SS-100-LT	100mm	16mm	M16×2 (Metric)	Hex Head	Q235 Carbon Steel	Hot-dip galvanizing (≥80μm)	14mm	9kN	Wooden Sleeper (Light Rail)	GB/T 152-2019, EN 13684-1
SS-125-Mainline	125mm	18mm	3/4"-10 (UNC)	Square Head	Q345 Carbon Steel	Electro-galvanizing (≥25μm)	16mm	13kN	Concrete Sleeper (Passenger)	GB/T 152-2019, AREMA 30
SS-150-HeavyHaul	150mm	20mm	M20×2.5 (Metric)	Hex Head	45# Carbon Steel	Dacromet (≥10μm) + Zinc Plating	18mm	19kN	Composite Sleeper (Freight)	GB/T 152-2019, AREMA 30
SS-90-Metro	90mm	14mm	M14×1.75 (Metric)	Countersunk Head	Q235 Carbon Steel	Epoxy Coating (≥50μm)	12mm	7kN	Wooden Sleeper (Metro)	GB/T 152-2019, TB/T 3395.2
SS-110-HSR-Aux	110mm	17mm	5/8"-11 (UNC)	Square Head	35# Carbon Steel	Hot-dip galvanizing (≥90μm)	15mm	11kN	Concrete Sleeper (HSR Aux)	GB/T 152-2019, TB/T 3395.3

Thread & Installation-Focused Inspection Checklist

Inspection Stage	Key Item	Test Method	Acceptance Criterion	Sampling Rule	Tool/Reference
Incoming Check	Material & Thread Precision	Handheld PMI + Thread Gauge	C: 0.17–0.24% (Q235); Thread Fit: 6g (Metric)/2A (UNC)	5 pcs/batch	Portable PMI Analyzer; Thread Plug Gauge
On-Site Installation	Torque & Fit	Torque Wrench + Drill Gauge	Torque: M16: 40–60N·m, 3/4": 70–90N·m; No Thread Stripping	15 pcs/100m track	Precision Torque Wrench; Drill Gauge
Short-Term Performance	Pull-Out Test	Portable Pull Tester	Pull-Out Force ≥90% of Min. Value; No Thread Damage Post-Test	3 pcs/km monthly	Digital Pull Tester
Long-Term Durability	Corrosion & Thread Wear	Salt-Spray Test + Thread Calipers	No Red Rust After 500h; Thread Diameter Wear ≤0.1mm	2 pcs/batch	Salt-Spray Chamber; Digital Thread Calipers
