Products Description
QU120 crane rail is a high-strength rail designed for heavy cranes, suitable for lifting equipment rails with large loads. Its 120kg/m weight and strong load-bearing capacity make it an ideal choice for high-load and high-frequency use environments, and is widely used in heavy industrial fields such as ports, steel mills, and shipyards. By using QU120 rails, the stability of the crane and long-term safe operation can be ensured.
Common applications of GB QU120 rails:
Port cranes: such as gantry cranes and bridge cranes at container terminals, used for handling containers and heavy goods.
Steel mills and metallurgical plants: used for lifting equipment rails inside steel mills to transport heavy steel products, raw materials, etc.
Shipyards: used for rails for large lifting equipment to transport large hulls or heavy equipment.
Heavy industrial equipment: such as crane rails for heavy equipment such as manufacturing plants and machinery production lines.
Material： U71Mn
Weight：118.10Kg/m
Length：12m
Standard：YB/T5055-2014
Chinese Standard Crane Rail U71Mn QU120
| Parameters | |||
| type | weight (kg/m) | material | length (m) |
| QU120 | 118.10 | U71Mn | 12 |
| rail height (mm) | bottom width (mm) | head width (mm) | web thickness (mm) |
| 170 | 170 | 120(129) | 44 |
Other Features
120kg/m: QU120 rail weighs 120 kg per meter, which is heavier than QU70 rail, which means it has higher load-bearing capacity and greater stability. It can support heavy-load lifting equipment and is suitable for applications that require higher strength and durability.
QU120 rails are usually used for rails of large bridge cranes, gantry cranes, tower cranes and other equipment. It is suitable for equipment that needs to carry extra-large loads, such as port loading and unloading, heavy industrial production lines, metallurgy and shipbuilding.
This rail is used for crane rails that carry high loads and large dynamic loads, especially in heavy manufacturing and logistics links such as ports, steel mills, and shipyards.
Crane Rail
| Crane Rail | Size | Rail Height | Bottom Width | Head Width | Web Thickness | Weightkg/m |
| QU70 | 120 | 120 | 70(76.5) | 28 | 52.80 | |
| QU80 | 130 | 130 | 80(87) | 32 | 63.69 | |
| QU100 | 150 | 150 | 100(108) | 38 | 88.96 | |
| QU120 | 170 | 170 | 120(129) | 44 | 118.10 |
Chinese Standard Crane Rail
