Products Description
GB 30kg rails are medium-weight rails, usually used for railway systems with lighter loads and low speeds. Its design and application are mainly suitable for some non-high-speed railway systems, such as industrial railways, mining railways, branch railways, etc.
The nominal weight of 30kg rails is 30 kilograms per meter, which is suitable for railway systems with low load and traffic density, and is usually used for lines that do not need to bear excessive transportation loads.
30kg rails are usually made of high-strength steel, such as alloy steel or carbon steel, and are heat treated (such as quenching, tempering, etc.) to improve their hardness, strength, wear resistance and corrosion resistance to ensure the durability and safety of the rails.
Although its load-bearing capacity is not as good as that of heavier rails, it can still meet normal use requirements under proper design and load.
Chinese Standard Crane Steel Rail 30KG
| Parameters | |||
| type | weight (kg/m) | material | length (m) |
| 30kg | 30.10 | Q235/55Q | 6-10m |
| rail height (mm) | bottom width (mm) | head width (mm) | web thinkness (mm) |
| 107.95 | 107.95 | 60.33 | 12.3 |
Other Features
Scope of application:
Industrial railways: GB 30kg rails are often used for laying industrial railways such as factories, mines, and storage areas, and are suitable for carrying light goods.
Branch railways: This light rail is suitable for branch lines or small railways connecting to trunk railways, especially railway systems with less traffic and lower speeds.
Light railways: For example, some local railways, short-distance railways, urban light railways, etc., also use 30kg rails as part of the railway track.
Chinese Standard Crane Steel Rail
About Us
Our company has continuously invested in the research and development of GB rail products, introduced advanced rail production technology and equipment from home and abroad, and is committed to developing more environmentally friendly, efficient and durable rail products. Our innovative technology not only improves the performance of rails, but also reduces production costs, bringing greater economic benefits to customers.
