Composite Railway Tie
A Composite Railway Tie is a type of railway tie (or sleeper) made from composite materials such as plastic, fiberglass, or a mixture of synthetic resins and fibers. These ties are designed to offer enhanced durability, resistance to environmental factors, and a longer lifespan compared to traditional wood or concrete ties. GNEE rail is as experts in rail fasteners, we provide a broad selection of products, from rail clips and tie plates to concrete and composite sleepers, wooden sleepers, rail spikes, and fastening systems. Our composite sleepers, made from HDPE, UHMWPE, FFU synthetic, and polyethylene, are customizable and globally certified. Feel free to connect with us!
Composite Railway Tie specification
Ambient temperature: -45 ℃ ~ 70 ℃
Machinability: The same as Timber.
Service life: More than 50 years.
Maintenance costs: significantly reduced.
Lifecycle costs: Minimal.
Density: The same as wood (740kg/m3).
Electrical conductivity: Very low.
Chemical resistance: Very high.
Custom manufacture: to millimetre precision.
Sustainability: 100% recyclable.
Composite Railway Tie material property
|
Item |
JIS E1203:2007 Strength |
(CJ/T399-2012) |
|
|
Material Strength |
Bending Strength |
min. 70 N/mm2 |
min. 80 N/mm2 |
|
Young 's modulus in flexure |
min. 6000 N/mm2 |
min. 7000 N/mm2 |
|
|
Withstand bending load |
min. 170 kN |
min. 170 kN |
|
|
Longitudinal compressive strength |
min. 40 N/mm2 |
min. 50 N/mm2 |
|
|
Shearing strength |
min. 7 N/mm2 |
min. 7 N/mm2 |
|
|
Adhesion shearing strength |
min. 7 N/mm2 (base-material breakage) |
min. 7 N/mm2 (base-material breakage) |
|
|
Electrical Properties |
Alternating-current breakdown voltage |
min. 20 kV |
min. 20 kV |
|
Direct-current insulation resistance |
min. 1 X 1010 Ω |
min. 1 X 1010 Ω |
|
|
Pulling Strength |
Track spike pulling strength |
min. 15 kN |
min. 20 kN |
|
Screw spike pulling strength |
min. 30 kN |
min. 40 kN |
|
|
Unit volume mass |
0.74土 0.1 g/cm3 |
0.74土 0.1 g/cm3 |
|
|
Amount of water absorption |
max. 10 mg/cm2 |
max. 10 mg/cm2 |
|
Composite Railway Tie for sale
