Description
Technical Parameters
Performance Test Data of Railway Fast Clips
| Clip Series | Wire Gauge (mm) | Material Composition | Hardness (HRC) | Tensile Strength (MPa) | Elastic Modulus (GPa) | Clamping Force Retention (%) | Impact Resistance (J) | Corrosion Resistance Test |
|---|---|---|---|---|---|---|---|---|
| FCP-15 | 15.0 | C:0.58-0.65, Si:1.50-2.00, Mn:0.70-1.00 | 43-47 | ≥1600 | 206-210 | ≥90 (after 3 years) | ≥12 | 500h salt spray (no rust) |
| FCP-17 | 17.5 | C:0.55-0.62, Si:1.60-2.10, Cr:0.80-1.10 | 45-49 | ≥1750 | 208-212 | ≥92 (after 3 years) | ≥14 | 1000h salt spray (no rust) |
| FCP-19 | 19.2 | C:0.60-0.67, Si:1.80-2.30, Mn:0.90-1.20 | 46-50 | ≥1800 | 210-215 | ≥88 (after 3 years) | ≥16 | 800h salt spray (no rust) |
| FCP-21 | 21.0 | C:0.52-0.59, Si:1.70-2.20, Mo:0.20-0.30 | 44-48 | ≥1700 | 207-211 | ≥91 (after 3 years) | ≥15 | 600h salt spray (no rust) |
| FCP-Mini | 12.8 | C:0.62-0.69, Si:1.40-1.80, Mn:0.60-0.90 | 42-46 | ≥1550 | 205-209 | ≥85 (after 3 years) | ≥10 | 400h salt spray (no rust) |
Product Specifications & Supply Details of Railway Fast Clips
| Clip Series | Overall Length (mm) | Working Height (mm) | Material Certification | Packaging Standard | MOQ (Minimum Order Quantity) | Lead Time | Compatible Rail Flange Width (mm) |
|---|---|---|---|---|---|---|---|
| FCP-15 | 185 ± 2 | 42 ± 1 | ISO 9001, CE | 500 pcs/wooden crate | 5,000 pcs | 15-20 workdays | 132-140 |
| FCP-17 | 205 ± 2 | 48 ± 1 | ISO 9001, CE, DIN | 300 pcs/wooden crate | 3,000 pcs | 20-25 workdays | 140-148 |
| FCP-19 | 220 ± 2 | 54 ± 1 | ISO 9001, CE, AREMA | 200 pcs/wooden crate | 2,000 pcs | 25-30 workdays | 148-156 |
| FCP-21 | 240 ± 2 | 60 ± 1 | ISO 9001, CE, GB | 150 pcs/wooden crate | 1,500 pcs | 30-35 workdays | 156-164 |
| FCP-Mini | 160 ± 2 | 36 ± 1 | ISO 9001, CE | 1000 pcs/wooden crate | 10,000 pcs | 12-18 workdays | 120-128 |
gnee-professional supplier
