Thread Connection Characteristics & Installation Torque Parameters
| Model No. | Matching Screw Spike Thread Spec | Thread Fit Class | Recommended Installation Torque (N·m) | Torque Retention Rate (10⁴ Cycles, %) | Thread Locking Mechanism | Screw Spike Material Grade | Thread Pull-Out Resistance (kN) | Core Thread Advantage |
|---|---|---|---|---|---|---|---|---|
| SKL1-TH | M24×2.5 | 6H/6g | 180-220 | ≥90 | Thread Locking Compound | 4.6 (Q235) | ≥85 | Cost-effective for conventional line fasteners |
| SKL3-TH | M24×2.5 | 6H/6g | 200-240 | ≥92 | Nylon Insert Lock Nut | 5.6 (35# Steel) | ≥95 | Vibration-resistant for urban rail |
| SKL12-TH | M24×2.5 | 6H/6g | 220-260 | ≥94 | Pre-Applied Thread Adhesive | 8.8 (45# Steel) | ≥110 | High-precision torque retention for high-speed rail |
| SKL14-TH | M24×2.5 | 6H/6g | 210-250 | ≥93 | Double-Layer Thread Lock | 5.6 (35# Steel) | ≥100 | Impact-resistant for heavy-haul lines |
| SKL15-TH | M27×3.0 | 6H/6g | 250-290 | ≥96 | Integrated Thread Lock Sleeve | 8.8 (45# Steel) | ≥125 | High-load resistance for ballastless track |
Environmental Durability & Corrosion Protection Performance
| Model No. | Salt Spray Corrosion Resistance (Hours) | Humidity Resistance (95% RH, °C) | High-Temperature Creep Resistance (100°C, 1000h, %) | Low-Temperature Brittleness Resistance (-40°C) | Corrosion Protection Coating | UV Resistance (1000h Irradiation) | Core Durability Advantage |
|---|---|---|---|---|---|---|---|
| SKL1-EN | ≥800 | 40 ± 2 | ≤5 | No Brittleness (Impact Test Pass) | Zinc Plating | No Visible Degradation | Reliable for inland temperate environments |
| SKL3-EN | ≥1000 | 45 ± 2 | ≤4 | No Brittleness (Impact Test Pass) | Dacromet Coating | No Visible Degradation | Humidity-resistant for urban rail networks |
| SKL12-EN | ≥1200 | 50 ± 2 | ≤3 | No Brittleness (Impact Test Pass) | Hot-Dip Galvanizing | No Visible Degradation | Extreme environment tolerance for high-speed rail |
| SKL14-EN | ≥1000 | 48 ± 2 | ≤3.5 | No Brittleness (Impact Test Pass) | Dacromet + Sealant | No Visible Degradation | Creep-resistant for heavy-haul long-term load |
| SKL15-EN | ≥1500 | 55 ± 2 | ≤2.5 | No Brittleness (Impact Test Pass) | Ceramic Coating | No Visible Degradation | Ultra-durable for ballastless track harsh conditions |
