SKL Clips For Railway Fastener

Railway Clip is used to fasten the rails to the underlying base plate together with the concrete sleeper. A variety of different types of heavy-duty clips are used to fasten the rails to the underlying baseplate or Sleeper, one common being the E Clip, which is shaped like a stubby paperclip. Another one is the SKL Tension Clamp, which is also the most widely used type all over the world. Others like KPO Clamp and Nabla Clip, also used in different situations.

Send Inquiry

Chat Now

Description

Technical Parameters

↵

Rail SKL CLIP Fastening System

The Railway SKL Clip is a heavy-duty elastic rail fastening component characterized by its omega-shaped (Ω) double-bend geometry. Manufactured from high-grade spring steel, it generates substantial and consistent toe load through multi-stage deflection, making it the preferred choice for high-speed railways, heavy-haul corridors, and tracks requiring exceptional longitudinal restraint and gauge retention under extreme dynamic conditions.

Technical Specifications:

Material Property	Specification	Performance Benefit
Chemical Composition	0.55–0.65% C, 1.4–1.7% Si, 0.6–0.9% Cr	High elastic limit
Tensile Strength	1,400–1,600 MPa	Fatigue resistance
Yield Ratio	>0.85	Elastic recovery
Impact Toughness	>25 J at -20°C	Cold climate reliability
Surface Hardness	42–48 HRC	Wear resistance
Microstructure	Tempered martensite	Long-term stability

Installation & Maintenance Perspective:

Manufactured from chromium-silicon alloyed spring steel for enhanced hardenability.
Undergoes quench and temper treatment to achieve uniform martensitic structure.
Surface decarburization strictly controlled to prevent fatigue crack initiation.
Inclusion purity monitored through ultrasonic testing to ensure material integrity.
Grain refinement optimized for balanced strength and ductility across section.

Maintenance & Operational Perspective

Reacts to wheel loads within milliseconds through elastic wave propagation.
Dampens high-frequency vibrations before they transfer to sleeper and ballast.
Adapts clamping force instantaneously to momentary load spikes from wheel irregularities.
Prevents resonant amplification through non-linear stiffness characteristics.
Returns to original position after each load cycle with zero permanent deformation.
