Railway Fast Clips - Scenario-Specific Customized Specifications
|
Model Code |
Application Scenario |
Customized Design Features |
Key Dimensions (mm) |
Material & Surface Treatment |
Core Performance Indicators |
Installation Tool |
|
FC-HSR350 |
High-Speed Rail (≥350km/h) |
Streamlined leg (reduced air resistance); Integrated anti-loosening notch |
Wire Diameter:14; Height:42; Opening Width:20 |
65Si2MnWA + Epoxy Powder Coating (80μm) |
Elastic Recovery Rate:≥96%; Fatigue Life:≥1.2×10⁷ cycles |
Digital Torque Wrench (50–60N·m) |
|
FC-HD40 |
Heavy-Haul Freight (Axle Load 40t) |
Thickened leg (7.0mm); Wear-resistant alloy contact surface |
Wire Diameter:16; Height:48; Opening Width:23 |
55SiMnMo + Zinc-Aluminum Coating (20μm) |
Toe Load:18–22kN; Tensile Strength:≥1500MPa |
Heavy-Duty Pneumatic Wrench |
|
FC-METRO20 |
Urban Metro (Underground) |
Insulated nylon sleeve (thickness 3mm); Corrosion-resistant core |
Wire Diameter:13; Height:38; Opening Width:18 |
60Si2MnA + Dacromet Coating (15μm) |
Insulation Resistance:≥10⁸Ω; Salt Spray Resistance:≥600h |
Electric Impact Wrench (40–50N·m) |
|
FC-MINE30 |
Mining Railway (Dust/Acid) |
Sealed leg structure; Acid-resistant PTFE coating |
Wire Diameter:15; Height:45; Opening Width:21 |
304 Stainless Steel + Electropolishing |
Acid Immersion Resistance:≥500h; Dust Proof Grade:IP65 |
Anti-Corrosion Pneumatic Wrench |
|
FC-LIGHT12 |
Light Rail (Tram) |
Lightweight hollow leg; Color-coded head (blue for 12kg/m rail) |
Wire Diameter:12; Height:32; Opening Width:16 |
50CrVA + Zinc Plating (10μm) |
Installation Force:≤25N·m; Weight:160g/pc |
Manual Torque Wrench (30–40N·m) |
Railway Fast Clips - Quality Inspection & Compliance Standards
|
Inspection Category |
Test Item |
Test Method |
Acceptance Criterion |
Compliance Standard |
Detection Equipment |
Sampling Ratio |
|
Mechanical Performance |
Tensile Strength |
Tensile testing machine (GB/T 228.1) |
≥1400MPa (for heavy-haul models); ≥1200MPa (for light rail models) |
GB/T 1222; ASTM A913 |
Electronic Tensile Tester |
1% per batch (min. 5pcs) |
|
Fatigue Life |
Fatigue testing machine (UIC 515-4) |
≥10⁷ cycles (35–60N·m cyclic load, no crack) |
UIC 864-3; DIN 536 |
Servo Hydraulic Fatigue Tester |
0.5% per batch (min. 3pcs) |
|
|
Elastic Deformation |
Displacement sensor (ISO 7438) |
Permanent deformation ≤0.5mm after 5000 load cycles |
ISO 7438; BS EN 13146 |
Laser Displacement Meter |
2% per batch (min. 10pcs) |
|
|
Corrosion Resistance |
Neutral Salt Spray |
Salt spray chamber (ISO 9227) |
≥500h (no red rust for general models); ≥800h (coastal models) |
ISO 9227; GB/T 10125 |
Programmable Salt Spray Tester |
1% per batch (min. 5pcs) |
|
Acid Spray |
Acid spray chamber (ASTM G85) |
≥300h (no corrosion for mining models) |
ASTM G85; DIN EN ISO 9227 |
Acid-Resistant Spray Tester |
0.5% per batch (min. 3pcs) |
|
|
Dimensional Accuracy |
Wire Diameter |
Digital micrometer (GB/T 1958) |
Tolerance: ±0.1mm (critical models); ±0.15mm (general models) |
GB/T 1958; ISO 8015 |
Digital Micrometer (0.001mm precision) |
5% per batch (min. 20pcs) |
|
Opening Width |
Vernier caliper (JIS B0601) |
Tolerance: ±0.2mm (all models) |
JIS B0601; BS EN 12642 |
Vernier Caliper (0.02mm precision) |
5% per batch (min. 20pcs) |
|
|
Material Compliance |
Chemical Composition |
Spectrometer (GB/T 4336) |
Match material grade requirements (e.g., 60Si2MnA: C 0.56-0.64wt%) |
GB/T 4336; ASTM E415 |
Optical Emission Spectrometer |
0.1% per batch (min. 2pcs) |
