Rail Screw Spike Fastening System
A Railway Screw Spike is a tapered, helically-threaded steel dowel specifically engineered for securing rails and baseplates to wooden sleepers through rotational insertion rather than impact driving. Its distinguishing feature is the coarse, deep-cut thread form that progressively engages wood fibers along the entire shank length, creating a compression-fit anchor with withdrawal resistance significantly exceeding that of cut spikes. The head incorporates a forged square or hex drive section with an integral collar that bears directly on the rail foot or tie plate, providing both vertical clamping and lateral restraint through thread-to-wood interference.
Technical Specifications:
| Feature Category | Key Benefit | Common Application |
|---|---|---|
| Buttress Thread | Maximum pull-out resistance directionally optimized | Steep gradients & braking zones |
| Hot-Dip Galvanizing | 50+ micron sacrificial protection | Coastal & humid environments |
| Lead-in Taper | Cross-threading prevention during installation | High-speed mechanized spiking |
| 4-6 TPI Pitch | Balanced grip vs. torque requirement | Softwood sleeper main lines |
| Proof Load Testing | 1.5x safety factor validation | Safety-critical turnouts |
| Elastic Embedment | Micro-movement absorption without loosening | Bridge approaches & transitions |
Installation & Maintenance Perspective:
- Buttress-style thread profile maximizes load-bearing surface on the pull-out side.
- Root diameter larger than shank prevents torsional shear failure during installation.
- Thread depth calculated to engage springwood and summerwood layers differentially.
- Lead-in taper at tip prevents cross-threading in pilot holes during initial engagement.
- Thread pitch of 4-6 threads per inch optimizes grip without excessive installation torque.
Maintenance & Operational Perspective
- Hot-dip galvanizing provides sacrificial zinc layer 50-85 microns thick.
- Sherardized coatings offer uniform diffusion layers for threaded areas without buildup.
- Bi-metal corrosion cells monitored between spike, plate, and sleeper materials.
- Creosote-compatible coatings prevent chemical degradation in treated sleepers.
- Periodic torque auditing reveals hidden corrosion before visible failure occurs.
Gnee Professional supplier
